EXPLORER-M Series
Self-cooling MPPT Solar Charge Controller
Product name： EXPLORER-M
Product model： EXPLORER-M Series——12V/24V 20A-60A
Time： 2019-01-24
INTRODUCTION:
A new generation of MPPT solar intelligent digital controller
1, self-heating, protection grade IP43
2, beautiful design, touch buttons, internal and external repair
3, four-stage charging to extend battery life
4, tracking efficiency as high as 99.8%
5, perfect protection function
6, can expand APP, host computer, and unlimited parallel
7, can monitor the entire system status, determine system matching, etc.
MODEL:
System voltage: DC12V/24V/36V/48V automatic identification
Rated current: 20A 30A 40A 50A 60A
Maximum PV (voc) voltage: 150V
CHARACTERISTICS:
1. Efficient MPPT algorithm, MPPT efficiency ≥99.5%
2. Integrated design, stable performance and high reliability
3. With current limiting charging function
4. IP43 level protection, natural cooling
5. Touch button, high-definition color display
6. Intelligent interactive experience
7. Dual RS485 communication interface, support for parallel communication
8. Battery type selection: sealed lead acid battery / flooded battery / gel battery, other battery types (such as lithium battery) can be customized
9. Four LOAD control modes: normally open / normally off mode, light control mode, dual time controller mode, light control + fixed time control mode
10. Support PC PC software / WiFi module cloud APP monitoring
11. CE, FCC, RoHS certification
